Fully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion Machine

Get your industrial wiring tasks done efficiently with our Fully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System. We are a trusted factory specializing in high-quality manufacturing.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Specification
  • Detailed Photos
Overview

Basic Info.

Model NO.
YH-STCJK03
Automatic Grade
Automatic
Installation
Vertical
Driven Type
Electric
Mould Life
300,000-1,000,000 Shots
Name
Fully Automatic Cable Crimping Housing Shell Ins
Power Supply
AC220V/50/60Hz Single Phase
Maximum Power
4.8kw
Air Pressure
0.4~0.6 MPa
Weight
1000kg
Processing Range
AWG18-AWG28
Cutting Precision
0.5mm+ Cutting Length*0.2%
Stripping Length
a End: 0.1-6.0mm (Insertion End),B End:0.1-10.0mm
Crimping Capacity
1.5kn
Maximum Number of Pins
20 Holes in a Single Row, up to 3 Rows
Maximum Pin Color Number
8 Colors (More Colors Must Be Customized)
Housing Shell Size
Max:40*25*25 Min:5*6*3
Transport Package
Wooden Case
Specification
22*25*60cm
Trademark
YH
Origin
China
HS Code
8479819000
Production Capacity
500 Per Month

Product Description



Fully Automatic Cable Crimping end Housing Shell Inserting Machine


This is a fully automatic cable double-end housing shell inserting machine. It is able to process of double-end cutting, stripping, terminal crimping and housing connector inserting.

Model: YH-STCJK03
Brand: Yuanhan


Features
  • Function: cable double-end cutting, stripping, terminal crimping and housing connector inserting.

  • 16 stations on both sides, independent synchronous cycle operation, can close any station independently, effectively improving production efficiency.

  • Independent double knife holder, convenient and quick to adjust the peeling depth.

  • The crimping machine adopts the HIWIN guide rail and digital crimping height adjustment.

  • Reversible defective product isolation method, 100% isolation of defective production.

  • Ultra-high efficiency, up to 6000 pcs/hour.


    Specification
    Model YH-STCJK02
    Power supply AC 220v
    Maximum power 4.8KW
    Air pressure 0.4~0.6 MPa
    Weight 1000KG
    Dimensions 2400L*1500W*1850H (excluding wire feeder and vibrating plate part)
    Function

    A end: Stripping, stripping broken core wire CCD detection, crimping, terminal appearance CCD detection, insertion;

    B end: Stripping, stripping and broken core wire CCD detection, twisting and tinning (optional), crimping, terminal appearance CCD detection, insertion.

    Processing range AWG18-AWG28
    Processing length 950≥L≥90mm
    Cutting precision 0.5mm+ cutting length*0.2%
    Stripping length A end: 0.1-6.0mm (insertion end),B end:0.1-10.0mm
    Crimping capacity 1.5KN
    Maximum number of PINs 20 holes in a single row, up to 3 rows
    Maximum PIN color number 8 colors (more colors must be customized)
    Housing shell size MAX:40*25*25 MIN:5*6*3
  • Detailed Photos

    Fully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion MachineFully Automatic Wire Strip Terminal Crimping and Housing Insertion Machine with CCD and Cfm System Housing Insertion Machine
